SPX W Series User Manual

4" Diameter
1
6" Diameter
1
8" Diameter
1
1
106050+ 107951+ POA POA
1a Indicator Stem - Control Top
106003+ 106004+ POA 128787+
1b Indicator Stem - used with yoke switch
-- -- -- 128787+
4 Cylinder
113099+ 113112+ POA 126871+
* 5 Bearing, Indicator Stem
102757+ 102757+ 102757+ 102757+
* 6 O-ring, Indicator Stem Nitrile
N70210 N70210 N70210 N70210
* 7 O-ring, Cylinder Nitrile
N70240 N70255 N70367 N70255
* 8 O-ring, Upper Seat Piston (qty 2 req) Nitrile
N70342 N70433 N70443 N70433
9 Cap Screw, 1/4-20 x .375" lg.
30-68 (4 req) 30-68 (8 req) 30-68 (12 req) 30-68 (8 req)
10 Lower Seat Piston & Spring Assembly 1-1/2"
113680+ -- --
2"
113679+ -- --
2-1/2" - 4"
-- 113678+ --
6'' -- -- POA
2-1/2" - 4" Tank Outlet -- 129868+
--
* 11 O-ring, Adjusting Sleeve (qty 2 req) Nitrile
N70214 N70219 N70219 N70219
12 Yoke 1-1/2"
109823+ -- --
2"
109940+ -- --
2-1/2''; 2-1/2'' - 3" Tank Outlet
-- 109928+ --
3"; 4" Tank Outlet
-- 109934+ --
4"
-- 109905+ --
6'' -- -- POA
POA
12a Yoke with 3rd. prox switch (not shown)
See Note 3 See Note 3 See Note 3 128532+
13 Vent Plug (not shown)
3023957+ 3023957+ 3023957+ 3023957+
* 14 Bearing, Main Piston (See note 5)
101995+ 102052+ 100256+ 102052+
* 15 Bearing, Adjusting Sleeve
106047+ 109919+ 109919+ 109919+
* 16 Bearing, Lifting Piston
109820+ 109920+ 109920+ 109920+
* 17 O-ring, Inner Yoke Nitrile
N70222 N70328 N70328 N70328
18 Spring, Upper Stem
101946+ 5901106+ 5901106+ 5901106+
20 Adjusting Nut, Upper Seat Lift
109822+ 109918+ 122345+ 122345+
Main Piston
117215+ 116472+ POA 116472+
Main Piston, Tank Outlet Valve
-- 116472A -- --
23 Upper Seat Piston
111507+ 111489+ 124555+ 124543+
24 Adjusting Sleeve, Lower Seat Clean
117439+ 116469+ POA 116469+
* 26 O-ring, Adjusting Nut Nitrile
N80026 N90222 N90222 N90222
* 29 O-ring, Outer Lower Seat Piston
Nitrile
N70337 N70427 N70433 N70427
30 Quick Exhaust (avail. upon request)
114680+ 114680+ 114680+ 114680+
33 Elbow swivel 90° 78-157 78-157 78-157 78-157
Note s:
PL5027-CH64
* Recommended Spare Parts
1.
2. Only required for valves without control top
3. For yokes with 3rd prox. switch, please contact factory.
4. Unless otherwise noted, quantity required is 1.
5. Quantity 2 on Tank Outlet Valve only.
For W72RS, 4-inch diameter actuator for 1-1/2 inch and 2-inch valves; 6-inch diameter actuator for 2-1/2 inch through
4-inch valves; 8-inch diameter actuator for 6-inch valves. (Does not apply to W72RSP Actuator.)
Indicator Stem - Visual
Item # Part Description
W72RS
22
W72RSP
119591+
POA
Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 83
W72RS/W72RSP Seat Lift Actuator
