PXS-710D Section 1

1.10 X-RAY COLLIMATOR:

Model: Collimare R72S

Rating: 80 kVp

LED Crosshairs (Center locator)

Light Field (LED, 12VDC @ 2A, 24VDC @ 1A or 24VAC @ 1A)

COMPLIES WITH DHHS RADIATION STANDARD 21 CFR SUBCHAPTER J

Conforms to ANSI/AAMI ES60601-1

Certified to CSA STD C22.2 No.60601-1

1.11 MECHANICAL SPECIFICATION:

X-RAY GENERATOR ASSEMBLY:

PHYSICAL SIZE: LENGTH WIDTH HEIGHT

12.6 in. 10.1 in. 13.2 in.

32 cm 25.7 cm 33.5 cm

GROSS WEIGHT: 29 lb., 13.1 KG

X-RAY SOURCE:

PHYSICAL SIZE: Reference figure 1.5

GROSS WEIGHT: 113 lb., 51.2 KG

PODIATRY BASE PLATFORM WEIGHT CAPACITY: 300 lb., 136 KG

AL EQUIVALENCE: Foot Plate Material: Less than 1.2mm AL

REMOTE CONTROL MODULE SR-115-RC (OPTIONAL):

PHYSICAL SIZE: LENGTH WIDTH HEIGHT

7.30 in. 3.30 in. 1.14 in.
