UNIT OPERATION
3.1 CONTROLS AND INDICATORS (CONTROL PANEL)
DESCRIPTION FUNCTION
1) GENERATOR POWER SWITCH Power Switch for the Generator. See
Section 3.2 (Item H) for the Digital
Imaging Panel Power Switch.
2) A.C. INPUT CONNECTOR Connects Control/Generator Assembly to
supply mains.
3) EXPOSURE SWITCH CONN Connects the exposure switch to the
Control/Generator assembly.
4) MA TEST JACK Test point for mA during the calibration
mode.
5) CONTROL CONNECTOR Connects the optional wall mount control
module.
6) RS-232 CONNECTOR RS-232 communications for remote host
control via OpalRad or other control
program. Note: See requirements for
responsible organizations in section
1.4 of this manual.
7) KVP METER A digital LED meter that indicates the kVp
prior to exposure.
8) MAS METER A digital LED meter that indicates the
computed MAS prior to exposure.
9) KVP ADJUST Two momentary switches that adjust the
kVp from 40 to 80 kVp in 1 kVp increments.
10) MAS ADJUST Two momentary switches that adjust the
MAS up or down from 0.1 to 30 mAs.
11) READY INDICATOR Color GREEN per 60601-1 3
rd
Ed. Illuminates
when unit is ready for operation.
Automatically prevents excessive operation
by means of a time delay circuit.
