Sri PXS-710D - Control Panel Description; Hand Switch Assembly

PXS-710D Section 3
48
3.1 C ONTINUED:
mAsIncrements
0.20 0.45 1.00 2.20 5.00 11.00 25.00 56.00 125.00
0.22 0.50 1.10 2.50 5.60 12.50 28.00 63.00 140.00
0.25 0.56 1.25 2.80 6.30 14.00 32.00 71.00 160.00
0.28 0.63 1.40 3.20 7.10 16.00 36.00 80.00 180.00
0.32 0.71 1.60 3.60 8.00 18.00 40.00 90.00 200.00
0.36 0.80 1.80 4.00 9.00 20.00 45.00 100.00

0.40 0.90 2.00 4.50 10.00 22.00 50.00 110.00

T ABLE 3.1
M AS I NCREMENTS C HART
F igure 3.3
C ontrol P anel D escriptions
F igure 3.4
H and S witch A ssembly
12
13
11
15
16
