PXS-710D Section 1
16
1.8 ELECTRICAL SPECIFICATIONS
MILLIAMPERES
Milliamperes will not deviate from the selected value by more than + 5% within
the operating line voltage range and within the specified range of line voltage
regulation.
KILOVOLTS
Kilovoltage will not deviate from the selected value by more than + 5% of full
scale
MAS
MAS will not deviate from the selected value more than + 8% or 0.2 mAs
whichever is greater within a range of 0.10 – 20 mAs.
MAXIMUM RATING
10 mA at 70 kVp DC
kVp Range Max Time mA Max mAs
40 –70 2.00 Sec. 10.0 20.0
LINE VOLTAGE REGULATION
5% maximum as measured at the x-ray control panel at maximum rated output.
INPUT ELECTRICAL RATING
For 115V Installation:
Line Voltage Range: 115VAC, 60 Hz
Momentary Max Line Current: 13 A, @ 70kVp and 10mA
Long Term Max Line Current: 2 A, @ Standby
Mains Resistance: Measured at the line input connector, not to
exceed 0.88Ω
