PXS-710D Section 3
49
3.2 SOURCE BASE
DESCRIPTION FUNCTION
A. BOOM ARM Controls the angle adjustment of the
Generator/Control Assembly.
B. SHUTTER KNOBS Adjusts X-Ray field size.
C. PATIENT SUPPORT RAIL Functions as a support point for patients.
D. PATIENT BASE Functions as positioning area for patient.
E. DETECTOR SLOT Functions as a positioning slot for the 20/20
imaging detector. One is provided for
Vertical alignment. Another is provided for
Horizontal alignment.
F. COLLIMATOR LAMP Left and Right buttons are provided on the
Collimator. Depressing any button
activates/de-activates the lamp, which is
automatically extinguished after
approximately 20 seconds to extend LED
life.
