3.1 CONTINUED:
12) X-RAY ON INDICATOR Color YELLOW per 60601-1 3
rd
Ed.
Illuminates when exposure switch is
depressed to indicate that x-ray’s are being
produced for the pre-set time interval. In
addition, an audio tone is generated at the
same time.
13) FAULT INDICATOR Color RED per 60601-1 3
rd
Ed. A lamp that
illuminates to indicate that a fault condition
has occurred. Refer to table 5.2 for a
description of fault conditions.
14) RESET BUTTON Clears and resets the front panel controls in
the event of a fault condition (reference
Table 5.2)
15) ANGLE INDICATOR An Angle indicator for the Horizontal Axis of
the Generator position.
16) HAND SWITCH A two-position switch that controls the
x-ray output. The first position is for prep
(ready) light goes out and comes back on
when unit is prepped), the second position
is for x-ray (x-ray light comes on while
x-rays are being produced). Premature
release of the exposure switch will
terminate the exposure and light the fault
lamp. Depress the RESET button to clear
the fault and Reset the timer.
NOTE: Internal fuses provide protection for auxiliary DC circuits;
replacements should be made by Authorized Source-Ray Personnel
only.
