PXS-710D Section 2
29
2.1 CONTINUED:
2) Remove the top polystyrene cushion (A), which secures the generator, and
put aside.
3) Cut off the 3 cable ties located on the Patient Handrails (B).
WARNING: The Podiatry Support Base contains a spring-loaded arm with
500 pounds of force.
4) Lift the Arm (C) up 90° and remove the Patient Back Handrail (D) and put aside.
5) Remove the Patient Side Handrails (E) from the cushions and put aside.
6) Remove the back handrail cushion from the box.
7) Remove the Podiatry Source (Model PXS-710D) from the box and put aside.
D
C
E
F
To Next Page
