6 Getting started
1. Make sure that the jumpers and switches are in the default position according to Figure 27.
2. Install the STLINK-V3E USB driver available on the www.st.com website.
3. Connect the board to the laptop using the CN8 ST-LINK connector, which is a USB Micro-B port.
4. Open a terminal like Tera Term and configure it with the following parameters:
– 115200 bps baud rate
– 8-bit data size
– No parity
5. The LD3 red COM LED is lit and the LD5 5V LED blinks.
6.
Provide Wi‑Fi
®
credential (SSID/PWD) via terminal.
7. Via the browser (client), it is possible to ping the server via IP.
Now, a web page appears on the browser and the web page content is accessible.
UM2839
Getting started
UM2839 - Rev 4
page 7/54
