Table 20. Pressure sensor I/O interface
I/O Configuration
PG2 INT/DRDY (Mems.INT_LPS22HH)
PH4 I2C_SCL
PH5 I2C_SDA
7.9.6 Time-of-Flight and gesture‑detection sensor (VL53L5)
VL53L5 is a state‑of‑the‑art, Time-of-Flight (ToF), laser-ranging sensor enhancing the ST FlightSense product
family.
The communication interface with STM32U585AII6Q is I
2
C. A shutdown control and interruption input is also
provided on STM32U585AII6Q. The I
2
C address is provided in Table 15. The I/O interface is described in
Table 20.
Caution: The laser output power must not be increased by any means and optics must not be used to focus the laser
beam. Use of controls or adjustments or performance of procedures other than those specified herein might
result in hazardous radiation exposure. Refer to the VL53L5 datasheet for more details.
Figure 24. Label for Class 1 laser products
Table 21. Time-of-Flight I/O interface
I/O
Configuration
PG5 GPIO1 (Mems.VLX_GPIO)
PH1 LPn (Mems.VL53_xshut)
PH4 I2C_SCL
PH5 I2C_SDA
7.9.7 STSAFE authentication and security for peripherals and IoT devices (STSAFA110S8SPL03)
The PF11 I/O is introduced to enable or shut down the STSAFE:
• Set PF11 to 0 to enable the STSAFE
• Set PF11 to 1 to disable the STSAFE
Table 22. STSAFE I/O configuration
I/O
Configuration
PF11 STASAFE enable/disable
PH4 I2C_SCL
PH5 I2C_SDA
UM2839
MEMS
UM2839 - Rev 4
page 30/54
