ST STM32F3 Series User Manual

The Cortex-M4 processor PM0214
20/262 PM0214 Rev 10
These registers are mutually exclusive bitfields in the 32-bit PSR. The bit assignment is
shown in Figure 3 and Figure 4.
Figure 3. APSR, IPSR and EPSR bit assignment
Figure 4. PSR bit assignment
Access these registers individually or as a combination of any two or all three registers,
using the register name as an argument to the MSR or MRS instructions. For example:
• Read all of the registers using PSR with the MRS instruction.
• Write to the APSR N, Z, C, V, and Q bits using APSR_nzcvq with the MSR instruction.
The PSR combinations and attributes are:
See the instruction descriptions MRS on page 186 and MSR on page 187 for more
information about how to access the program status registers.
Table 4. PSR register combinations
Register Type Combination
PSR read-write
(1), (2)
1. The processor ignores writes to the IPSR bits.
2. Reads of the EPSR bits return zero, and the processor ignores writes to the these bits
APSR, EPSR, and IPSR
IEPSR read-only EPSR and IPSR
IAPSR read-write
(1)
APSR and IPSR
EAPSR read-write
(2)
APSR and EPSR
25 24 23
Reserved ISR_NUMBER
31 30 29 28 27
NZCV
0
Reserved
APSR
IPSR
EPSR
Reserved Reserved
26 16 15 10 9
ReservedICI/IT ICI/ITT
Q
8
1920
GE[3:0]Reserved
25 24 2331 30 29 28 27
NZCV
0
PSR
Reserved
26 16 15 10 9
ICI/IT
Q
8
1920
GE[3:0]Reserved
ISR_NUMBER
