4.5 SysTick timer (STK)
The processor has a 24-bit system timer, SysTick, that counts down from the reload value to
zero, reloads (wraps to) the value in the STK_LOAD register on the next clock edge, then
counts down on subsequent clocks.
When the processor is halted for debugging the counter does not decrement.
Table 54. System timer registers summary
Address Name Type
Required
privilege
Reset value Description
0xE000E010 STK_CTRL RW Privileged 0x00000000
SysTick control and status register (STK_CTRL)
on page 247
0xE000E014 STK_LOAD RW Privileged Unknown
SysTick reload value register (STK_LOAD) on
page 248
0xE000E018 STK_VAL RW Privileged Unknown
SysTick current value register (STK_VAL) on
page 249
0xE000E01C STK_CALIB RO Privileged 0xC0000000
SysTick calibration value register (STK_CALIB)
on page 250
