4.5.6 SysTick register map
The table provided shows the SysTick register map and reset values. The base address of
the SysTick register block is 0xE000 E010.
Table 55. SysTick register map and reset values
Offset Register
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0x00
STK_CTRL
Reserved
COUNTFLAG
Reserved
CLKSOURCE
TICK INT
EN ABLE
Reset Value 0 1 0 0
0x04
STK_LOAD
Reserved
RELOAD[23:0]
Reset Value 000000000000000000000000
0x08
STK_VAL
Reserved
CURRENT[23:0]
Reset Value 000000000000000000000000
0x0C
STK_CALIB
Reserved
TENMS[23:0]
Reset Value 000000000000000000000000
