ST STM32U5 Getting Started

Table 1. Package summary for STM32U5 devices
Package Size (mm)
Pitch
(mm)
Height (mm)
STM32U535/
545xx
STM32U575/
585xx
STM32U59/
5Axxx
STM32U5F/
5Gxxx
LQFP48 7 × 7 0.5 1.6 X X - -
UFQFPN48 7 × 7 0.5 0.6 X X - -
LQFP64 10 × 10 0.5 1.6 X X X -
UFBGA64 5 × 5 0.5 0.6 X - - -
LQFP100 14 × 14 0.5 1.6 X X X X
UFBGA100 7 × 7 0.5 0.6 X - - -
UFBGA132 7 × 7 0.5 0.6 - X X -
LQFP144 20 × 20 0.5 1.6 - X X -
UFBGA169
(1)
7 × 7 0.5 0.6 - X - -
TFBGA169
(1)
7 × 7 0.5 1.1 - - X -
LQFP48 SMPS 7 × 7 0.5 1.6 X X - -
UFQFPN48 SMPS 7 × 7 0.5 0.6 X X - -
WLCSP56 SMPS 3.38 × 3.38 0.4 0.59 X - - -
LQFP64 SMPS 10 × 10 0.5 1.6 X X X -
UFBGA64 SMPS 5 × 5 0.5 0.6 X - - -
WLCSP72 SMPS 3.38 × 3.38 0.35 0.58 X - - -
WLCSP90 SMPS 4.20 × 3.95 0.40 0.59 - X - -
LQFP100 SMPS 14 × 14 0.5 1.6 X X X X
LQFP100 DSI SMPS 14 × 14 0.5 1.6 - - - X
UFBGA100 SMPS 7 × 7 0.5 0.6 X - - -
UFBGA132 SMPS 7 × 7 0.5 0.6 - X X -
LQFP144 SMPS 20 × 20 0.5 1.6 - X X -
LQFP144 DSI SMPS 20 × 20 0.5 1.6 - - - X
UFBGA144 DSI SMPS 10 × 10 0.8 0.850 - - - X
WLCSP150 SMPS 5.38 × 5.47 0.4 0.58 - - X -
WLCSP150 DSI SMPS 5.38 × 5.47 0.4 0.58 - - X -
UFBGA169 SMPS
(1)
7 × 7 0.5 0.6 - X - -
TFBGA169 SMPS
(1)
7 × 7 0.5 1.1 - - X -
WLCSP208 DSI SMPS
-
(2)
0.35 0.58 - - X X
TFBGA216 DSI SMPS 13 × 13 0.8 1.1 - - X X
1. For more information about the compatibility between UFBGA169 and TFBGA169, refer to Section 3.2.
2. Size in mm for STM32U59/5Axxx: 5.38 × 5.47
Size in mm for STM32U5F/5Gxxx: 5.8 × 5.6
3.2
Conversion from UFBGA169 to TFBGA169 boards
The UFBGA169 and TFBGA169 packages are compatible. However, it is important to note that the TFBGA169
balls have a larger diameter than the UFBGA169 balls, while the pitch of both packages is the same. To ensure
compatibility between the two packages, STMicroelectronics recommends maintaining a 280 µm solder mask
opening on the PCB. Additionally, customers must consider the height difference between the TFBGA169 and
UFBGA169 packages when designing their application.
AN5373
Conversion from UFBGA169 to TFBGA169 boards
AN5373 - Rev 6
page 22/47
