Definition Bridge
Setting
(1)
Comment
PB10
SB61
ON PB10 used as QSPI_CLK
SB62
OFF PB10 not used as TIMER for motor Control
ON PB10 used as TIMER for motor Control
TIMER_C_PWM1 /
User-Button
PA0
SB60
OFF
PA0 not used as TIMER for motor control, reserved for User
button
ON
PA0 can be used as TIMER for motor control, can’t be used as
User button
QSPI_IO3 /
TIMER_A_BKIN1
PE15
SB66
OFF PE15 not used as QSPI_IO3
ON PE15 used as QSPI_IO3
SB67
OFF PE15 not used as TIMER for motor Control
ON PE15 used as TIMER for motor Control
QSPI_IO0 /
TIMER_A_PWM3N
PE12
SB68
OFF PE12 not used as QSPI_IO0
ON PE12 used as QSPI_IO0
SB69
OFF PE12 not used as TIMER for motor Control
ON PE12 used as TIMER for motor Control
QSPI_IO2 /
TIMER_A_BKIN2
PE14
SB70
OFF PE14 not used as QSPI_IO2
ON PE14 used as QSPI_IO2
SB71
OFF PE14 not used as TIMER for motor Control
ON PE14 used as TIMER for motor Control
1. The default configuration is in bold.
UM2861
Solder bridge configuration for the expansion connector
UM2861 - Rev 2
page 39/49
