ST700 Dash Display System Installation
© Stack
17
❑ You may need to have more than one possible location available
for the lap-timing sensor on your vehicle to allow for the layout
of different tracks. Consider installing one on each side of the
vehicle.
❑ Where the track has more than one trackside beacon, you may
set up the ST700 Dash Display System to ignore additional IR
beacons for a period after it senses the first beacon. This ‘lap
masking’ feature prevents multiple triggering within each lap.
2. Attach the wire labelled ‘LAP’ of the harness to the sensor at the 4–
way ‘Sure–Seal’ connector. Take care to assemble this connector in
the correct orientation. Press the two halves of the connector fully
together to ensure a good waterproof seal.
Use a rigid mounting bracket to attach the sensor to the outside of the
vehicle where it can detect the signals from the trackside beacon. Use
the two M18 × 1 mm threaded nuts supplied to secure the sensor.
