Maintenance ST700 Dash Display System
72
Specification
Physical and environmental
Size Front of dash 88mm Ø × 8mm (3.5” Ø × 0.3”)
Behind dash 80mm Ø × 68mm (3.15” Ø × 2.7”)
Overall 88mm Ø × 76mm (3.5” Ø × 3.0”)
Mounting Hole 80mm (3.15”) diameter
Rear clearance 90mm (3.5”)
Fixing thread 2 × M4 × 1.5 × 20L (7.0 AF ~ 9/32” AF)
Power 8 to 18VDC 200mA typ 500mA max
Internal auto–reset 500mA fuse
Weight 500g (1.1 pounds) including harness
Temperature Operating –20°C to +80°C (–4°F to 176°F)
Storage –30°C to +90°C (–22°F to 194°F)
Vibration resistance 15G 50Hz to 2kHz
12Hr 3× axis (36 Hr total)
Shock resistance 500m/s (30ms)
1600ft/s (30ms)
Sealing IP67
Humidity 0 to 95% RH non–condensing
EMC EN50081–2
