Power–on the ST700 Dash Display System
Switch on the vehicle ignition. You should see the following indications
on the ST700 Dash Display System display:
❑ The dial illumination will turn on.
❑ The display backlighting will turn on.
If you have configured the ST700 Dash Display System for a low inten-
sity of backlight, it might be difficult to see the above illumination fea-
tures.
❑ The four shift lights and the alarm LED should show red briefly and
then go off. Because it is possible to change the intensity of the shift
lights it might be difficult to see these indications on the lowest
intensity setting if the ambient light is very bright.
❑ The tachometer needle will move fully anticlockwise to reset
against its stop. The needle will then settle on zero briefly and then
move to the current engine speed (if the engine is running).
❑ The display will briefly show the version of software in use and will
then show the speed layer.
If none of these indications appears when you power–on the system,
consult the troubleshooting instructions starting on page 62. Contact
Stack for advice if necessary using the contact details on page 75.
