Installation ST700 Dash Display System
8
INSTALLATION
You do not need complicated tools or special training to install the ST700
Dash Display System. To gain the benefits of using this quality instru-
ment all you need are a few basic workshop tools, the willingness to
read and follow these instructions carefully and the time to complete
each task in sequence.
Refer to the instructions between page 43 and page 59 for instruc-
tions to set up the ST700 Dash Display System display and alarm lim-
its specifically for your vehicle.
Product Installation
The installation process begins when you start to install the wiring har-
ness, the controls and the ST700 Dash Display System display. After you
have completed these tasks, you can fit and connect the options and
sensors included with your system. You may then connect the ST700
Dash Display System to the vehicle electrical supply.
You will need to cut a hole into the instrument panel to accept the ST700
Dash Display System instrument display. Choose a suitable position for
it:
❑ Mount the ST700 Dash Display System display on the instrument
panel so that the driver can see it easily, looking either through or
over the steering wheel, as shown in Figure 1.
