ST700 Dash Display System Installation
© Stack
25
3. Connect the wiring harness to the sensor at the spade terminals.
Oil pressure switch
You may connect the engine oil pressure switch to the ST700 Dash Dis-
play System instead of a Stack pressure sensor. This switch will be ‘open’
when the oil pressure is high and will close when the oil pressure falls
below its operating point and will cause the low oil pressure alarm to
display. To use the engine oil pressure switch as an input to the system,
select the option to use a switch from the Sensor 2 input menu (descr-
ibed on page56). This will then mean that Display Layer 5 (described
on page34) will not be shown.
Temperature Sensor options
You may use temperature sensors to monitor the following conditions:
Table 4: Temperature sensors
Monitored condition Stack Sensor types
Air temperature ST765, ST769
Axle temperature ST760, ST761, ST762,ST764, ST769
Differential temperature ST760, ST761, ST762,ST764, ST769
Gear temperature ST760, ST761, ST762,ST764, ST769
