Installation ST700 Dash Display System
26
You may set up the ST700 Dash Display System to display tempera-
ture measurements using °C or °F, and you may set the system to alert
the driver if the monitored value triggers a pre–set alarm—refer to
page 56 for relevant instructions.
1. Depending on the condition that you wish to monitor on your vehi-
cle, choose a suitable location for the sensor:
❑ Avoid mounting the sensor near sources of intense heat.
Oil temperature ST760, ST761, ST762,ST764, ST769
Water temperature ST760, ST761, ST762,ST764, ST769
Table 5: Temperature sensor ranges
Sensor type Temperature range
ST760 ST761 ST762 ST764 –20 °C to 150 °C (0°F to 300 °F)
ST765 –30 °C to 140 °C (–20°F to 285 °F)
ST769 –30 °C to 150 °C (–20 °F to 300 °F)
Table 4: Temperature sensors (Continued)
Monitored condition Stack Sensor types
