Installation ST700 Dash Display System
14
Engine Speed Measurement
This connection is dependent on your ignition system. You should
read these instructions carefully and make certain you have identified
the correct connection point before you begin.
To measure engine speed you must make the correct connections be-
tween the ST700 Dash Display System and the vehicle ignition system.
Contact Stack for advice if you have a complicated ignition system.
If you cannot use any of these engine speed connections, you may use
the optional Stack ST697 HT pick-up to get a signal from an ignition
lead.
Table 1: Connection to the ignition system
Ignition System Connection point (Orange wire)
Coil and Points Coil negative (Low tension)
HEI Systems Coil negative (Low tension)
Magneto (external or internal) Ground switch terminal (magneto
side)
MSD Tachometer output
Magneto CD (2-stroke) Use HT pick up (ST697)
To Next Page
