Star TSP650 - 11-1. Parallel Interface Model

– 34 –
No. 1 2 3 4 5 6 7 8 No. 1 2 3 4
DIP-SW 1 DIP-SW 2
11-1. ParallelInterfaceModel
ON ON
OFF OFF
DIP-SW 1
Switch1-1 Commandemulation
ON Star Mode
OFF ESC/POS Mode
e factory settings of DIP switch are all on.
e functions of switches 1-2 through 1-8 will change according to the command emulation
that has been set using switch 1-1.
(1) Star mode
Switch Function ON OFF
1-1 Command emulation Always ON
1-2 Should not be changed (Should be set to on)
1-3 Should not be changed (Should be set to on)
1-4 Sensor adjustment Invalid Valid
1-5 Pin #31 (INIT) reset signal Valid Invalid
1-6 Handshaking conditions
(conditions for BUSY)
Oine or receive
buer full
Receive buer full
1-7 ASB function *1 Invalid Valid
1-8 NSB function *2 Invalid Valid
(2) ESC/POS mode
Switch Function ON OFF
1-1 Command emulation Always OFF
1-2 Graphic adjustment 203 DPI 180 DPI
1-3 Should not be changed (Should be set to on)
1-4 Sensor adjustment Invalid Valid
1-5 Pin #31 (INIT) reset signal Valid Invalid
1-6 Handshaking conditions
(conditions for BUSY)
Oine or receive
buer full
Receive buer full
1-7 ASB function *1 Invalid Valid
1-8 Should not be changed (Should be set to on)
*1 ASB Function
When this function is enabled, status information is automatically sent to the host whenever the
printer status changes (such as when the cover is opened, paper runs out, or an error occurs).
For information about automatic status information transmission, refer to the separate Program-
mer's Manual (Star Line Mode and ESC/POS Mode).
