Star TSP650 - Ethernetinterface Model

– 41 –
No. 1 2 3 4 5 6 7 8 No. 1 2 3 4
DIP-SW 1 DIP-SW 2
11-4. EthernetInterface Model
ON ON
OFF OFF
DIP-SW 1
Switch 1-1 Command emulation
ON Star Mode
OFF ESC/POS Mode
e factory settings of DIP switch are all on.
e functions of switches 1-2 through 1-8 will change according to the command emulation
that has been set using switche 1-1.
(1) Star Line Mode
Switch Function ON OFF
1-1 Command emulation Always ON
1-2 Should not be changed (Should be set to on)
1-3 Should not be changed (Should be set to on)
1-4 Sensor adjustment Invalid Valid
1-5 Should not be changed (Should be set to on)
1-6 Handshaking conditions
(conditions for BUSY)
Offline or receive
buffer full
Receive buffer full
1-7 ASB function *1 Valid Invalid
1-8 NSB function *2 Valid Invalid
*1 ASB Function
When this function is enabled, status information is automatically sent to the host whenever the
printer status changes (such as when the cover is opened, paper runs out, or an error occurs).
For information about automatic status information transmission, refer to the separate Program-
mer's Manual (Star Line Mode and ESC/POS Mode).
*2 NSB Function
When this function is enabled, status information is sent automatically whenever the printer
enters into reverse forwarding mode.
For information about automatic status information transmission, refer to the separate Program-
mer's Manual (Star Line Mode).
