– 40 –
(2) ESC/POS mode
Switch Function ON OFF
1-1 Command emulation Always OFF
1-2
Graphic adjustment
203 DPI 180 DPI
1-3 Should not be changed (Should be set to on)
1-4 Sensor adjustment Invalid Valid
1-5 USB mode Printer class Vendor class
1-6 Handshaking conditions
(conditions for BUSY)
Offline or receive
buffer full
Receive buffer full
1-7 ASB function *1 Printer class Valid Invalid
Vendor class Invalid Valid
1-8 Should not be changed (Should be set to on)
*1 ASB Function
When this function is enabled, status information is automatically sent to the host whenever the
printer status changes (such as when the cover is opened, paper runs out, or an error occurs).
For information about automatic status information transmission, refer to the separate Program-
mer's Manual (Star Line Mode and ESC/POS Mode).
DIP-SW 2
Switch Function ON OFF
2-1
Always ON Should be set to on
2-2
2-3
2-4
The factory settings of DIP switch are all on.
