Star TSP650 - 13-3. Cable Connections

– 48 –
1
2
3
4
5
6
1
2
3
4
5
6
7
8
20
FG FG
TXD
RXD
RTS
CTS
DSR
20
25
7
SG
DTR
INIT
3
2
7
8
6
5
1
4
TXD
RXD
RTS
CTS
DSR
SG
DCD
DTR
Printer side Host side
25 pin 9 pin
13-3. CableConnections
e followings are a recommended interface cable connections.
Note: Use shielded wire less than 3 m in length.
