PART
20
764333-676
UNITS PER
ASSEMBLY
S
V
C
FIG. &
ITEM
NO.
PART
NUMBER
5- FLUID AND AIR COMPONENTS...................................................... X
1 ASSEMBLY, Drain Block (See Figure 9)............................................ 1
2 100596 GASKET, Drain Block To Heater ....................................................... 1
3 100681 GASKET, Heater Element.................................................................. 1
4 452202 BOLTS, Heater Housing, 5/16-18 x 7/8" ............................................ 8
5 450209 LOCKWASHER, 5/16......................................................................... 8
6 450210 WASHER, Flat, 5/16........................................................................... 8
7 100614 DRAIN, Transition Block..................................................................... 1
8 452001 SCREW, Button Head, #10-32 x 3/8"................................................. 6
9 450201 LOCKWASHER, #10.......................................................................... 8
10 450211 WASHER, Flat, #10............................................................................ 12
11 200176 PUMP, High Pressure ........................................................................ 1
200697 • POPPETS, High Pressure Pump (Not Shown)................................ 2
12 453005 NUT, Hex. #10-32 .............................................................................. 2
13 100523 BRACKET. Pump............................................................................... 1
14 452105 SCREW, Button Head, 1/4-20 x 3/8".................................................. 4
15 100590 CUSHION, Pump Bracket .................................................................. 1
16 450207 LOCKWASHER, 1/4-20...................................................................... 4
17 450208 WASHER, Flat, 1/4-20 .......................................................................
4
18
453006 WASHER, Nut, 1/4-20........................................................................ 4
19 400277 STUD, Mounting Plate........................................................................ 4
20 200740 ASSEMBLY, Circulation Pump, Magnetic Drive................................. 1
200966 • IMPELLER KIT (for Circulation Pumps manufactured by
Gormann-Rupp only) (Not Shown)
450400 GROMMET, 1/2" OD x 3/16" ID ......................................................... 8
21 200654 ASSEMBLY, Pinch Valve Branch....................................................... 1
22 400726 BODY, Valve ...................................................................................... 2
23 400420 SLEEVE, Valve .................................................................................. 2
400033 • GREASE, High Vacuum (Not Shown).............................................. A/R
400032 • COMPOUND, Anti-Sieze (Not Shown) ............................................ A/R
24 10004458 REGULATOR, Air (PR2) .................................................................... 1
25 400037 MOUNT, Adhesive Backed ................................................................ A/R
26 100329 SHIM, Drain Block.............................................................................. 3
27 400235 ADHESIVE, Loctite 222 (Not shown) ................................................. A/R
28 200181 BLOCK, HP Trans. with Concentration Probes ................................. 1
29 200656 ASSEMBLY, Cross Block................................................................... 1
30 100359 GASKET, HP (Transition Block to Circ Pinch Sleeve Assembly)....... 1
31 452010 SCREW, Button Head, #10-32 x 5/8"................................................. 4
32 200137 ASSEMBLY, Heater Housing, Stainless Steel ................................... 1
33 500106 Heater Element (Not Shown) .............................................................
1
34 Item # Not Used
35 450600 O-Ring, Large..................................................................................... 2
36 200154 VALVE, Dual Inlet Water (SOL5 & SOL7).......................................... 1
37 400696 VALVE, Drain Check (CK8)................................................................ 1
200696 • KIT, Rebuild, CK8 ............................................................................ A/R
38 ASSEMBLY, Air Manifold (See Figure 6)........................................... 1
39 ASSEMBLY, Float Block (See Figure 7) ............................................ 1
45 2004 SCREW, 10-32 x 1/2" SS................................................................... 4
40 A1503 FILTER, Sterile (AIR) ......................................................................... 1
To Next Page
