Steris SYSTEM 1E - Page 148

S
V
C
DESCRIPTION
39
764333-676
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
14- P 10004600 CONTROL ASSEMBLY, DOMESTIC ............................................... X
1 (Not Used)
2 (Not Used)
3 HOUSING, Take-up Motor (See Figure 15)........................................ 1
4 10004601 HOUSING, Control.............................................................................. 1
5 10004620 TOUCH PANEL, Domestic ................................................................. 1
6 P 755718 203 PROGRAM CHIP SET........................................................................ 1
7 P 093915 177 DISPLAY............................................................................................. 1
8 P 093922 504 BRACKET, Display Mounting. ............................................................ 1
9 P 093914 003 PRINTER HEADER ASSEMBLY........................................................ 1
10 P 146665 002 * CONTROL BOARD (See Modification Note)...................................... 1
P 129376 188 • FUSE, 630 MA, VDA
P 093915 047 • BATTERY, Smart
P 129361 870 • DRIVER, Chip
11 P 146665 359 * COVER, BTM Board........................................................................... 1
12 P 136817 136 WELDMENT, Shield ........................................................................... 1
13 P 093922 484 BRACKET, Support ............................................................................ 1
14 P 093912 226 SCREW, Flange Lock, #6-32 x 1/4".................................................... 9
15 P 129376 349 PLUG BUTTON .................................................................................. 1
16 P 129376 340 SCREW, Flange Lock, #6-32 x 3/8".................................................... 9
17 P 084121 002 NUT, Keps, #6-32 ............................................................................... 5
18 P 129376 331 STANDOFF, (Male x Female), #6-32 x 3/8" (Nylon)........................... 6
19 P 129376 337 HEADER, Right Angle (15 Pin)........................................................... 1
20 P 129326 001 MOUNT, Cable Tie ............................................................................. 1
21 P 084104 001 WIRE, Tie............................................................................................ 1
22 PRINTER HARNESS ASSEMBLY (See Figure 18) ........................... 1
23 DISPLAY HARNESS ASSEMBLY (See Figure 18)............................ 1
24 P 136817 129 SERIAL PORT HARNESS.................................................................. 1
25 P 129376 338 HEADER, Straight (5 Pin)................................................................... 1
26 P 129376 332 SCREW, Pan Head, #6-32 x 1/4" (Nylon)........................................... 4
27 P 129376 333 NUT, Hex, #6-32 (Nylon) .................................................................... 8
28 P 093912 152 STANDOFF, (Male x Female), #6-32 x 3/8" ....................................... 1
29 P 093912 380 SCREWLOCK KIT .............................................................................. 1
30 P 093922 077 LABEL (ESD and Shock Hazard) ....................................................... 1
31 P 129376 341 BUMPER, Adhesive-Backed............................................................... 2
32 P 129376 347 SCREW, Pan Head, #6-32 x 1/2" (Nylon)........................................... 2
33 P 093912 157 STANDOFF, (Male x Female), #6-32 x 1" .......................................... 2
* MODIFICATION NOTE: Before installing CONTROL BOARD (Item
#10) to shield weldment (Item #12), remove R55 and R56 Resistors.
These Resistors are not used in this application, and create an
interference.
