10-5
3. Temporarily connect the hook on the outside
chain as shown.
4. Pull the middle chain as tight as possible and
connect it to the hook.
5. Pull both ends of the outside chain as tight as
possible and close the hook .
6. Ensure that each hook lies flat on the tire side-
walls. Also, make sure that the chains are not
twisted.
7. Fasten extra chain links with a metal wire to pre-
vent them from hitting against other vehicle
components.
8. Fit the spring band . Attach the hooks of the
spring band to the chain at regular intervals, with
the hook ends facing outward.
9. After driving the vehicle for 5 to 10 minutes,
check the chains. Tighten any loose chains and
connect any loosened hooks.
Z11190
Z11191
GOOD BAD
Z09329a
Z09330
