8-3
NOTE:
• The heater uses the heat produced by the
engine. Therefore, warm air is not available until
the engine is warm.
• As the engine warms up with the vehicle parked,
use the engine warm-up switch to heat the cab
faster. The engine warm-up switch is on the
instrument cluster bezel.
1 Using the climate control panel
Air selection switch
Fan switch
Temperature control switch
Recirculation button
1.1 Fan switch
The fan switch allows you to adjust the fan speed.
To increase fan speed, turn the dial clockwise (in
the direction of arrow ). To reduce fan speed, turn
the dial counterclockwise (in the direction of arrow
).
1.2 Temperature control switch
The temperature control switch allows you to adjust
the cab temperature. To make the cab warmer, turn
the dial clockwise (in the direction of arrow ). To
make the cab cooler, turn the dial counterclockwise
(in the direction of arrow ).
Heater
Z11305
Z05610
Z05611
