11-45
1 Clutch pedal free play
1. Shut down the engine.
2. Set the parking brake and make sure the shift
lever is in neutral.
3. Press down with one finger on the center of the
pedal pad to the point where resistance is felt.
4. Measure the amount of clutch pedal movement
between these two points. This is the clutch
pedal free play . If the free play is not within
these limits, contact an authorized Sterling ser-
vice facility.
2Clutch wear
1. Make sure that the clutch pedal operates with-
out unusual noise or excessive resistance.
2. Depress the clutch pedal. There should be no
vibration or shudder in the clutch pedal.
3. Move the shift lever. The shift lever should move
easily from gear to gear.
4. Release the clutch pedal slowly. The clutch
should engage smoothly without slipping.
5. If the clutch shows signs of wear, replace it at an
authorized Sterling service facility.
1 Inflation pressure check
•
Always check tire pressure before driving, when
the tires are still cool. Make sure that the valve
caps are securely fitted on each tire.
• The tire tread profile can give a rough estimate
of the tire pressure. If the tires appear incorrectly
inflated, check and adjust the air pressure
before operating the vehicle.
Properly inflated
Overinflated
Underinflated
• Use an air gauge for precise measurement. If
your vehicle uses low-profile tires, the air pres-
sure must be checked using an air gauge.
Clutch pedal free play
(at center of pedal pad)
0.008 to 0.157 in
(0.2 to 4.0 mm)
Tire checking
Inspection
intervals
Daily pretrip inspection and
every 6000 miles (10 000 km)
Z11613
Z10801b
