13-4 Service data
Service specifications
Description Standard value
Engine idle speed 625 to 675 rpm
Engine valve lash
Intake 0.016 in (0.4 mm)
Exhaust 0.020 in (0.5 mm)
Intake manifold bolt torque value 30 lbf·ft (41 N·m)
Exhaust manifold nut torque value 17 lbf·ft (23 N·m)
Cranking power of 12-volt maintenance-free batteries 799 CCA
Belt tension [amount of deflection
under a 22 lb (98 N) pressure at the
point midway between pulleys]
Fan belt
Vehicles without air
conditioner
New belt (when installed):
0.35 to 0.43 in
(9 to 11 mm)
Used belt (when inspected
or reinstalled):
0.43 to 0.51 in
(11 to 13 mm)
Vehicles with air
conditioner
New belt (when installed):
0.28 to 0.35 in
(7 to 9 mm)
Used belt (when inspected
or reinstalled):
0.39 to 0.43 in
(10 to 11 mm)
Coolant quantity
About 17 quarts
(16 liters)
Clutch pedal free play (at center of pedal pad)
0.008 to 0.157 in
(0.2 to 4.0 mm)
Brake pedal free play (at center of pedal pad)
0.004 to 0.118 in
(0.1 to 3.0 mm)
Fully depressed brake pedal to floor clearance 0.79 in (20 mm) or more
Parking brake lever stroke 7 to 9 notches
Steering wheel play (measured on the outside diameter of steering wheel)
0.20 to 1.97 in
(5 to 50 mm)
M18 Suspension U-bolt nut torque value
215 to 290 lbf·ft
(292 to 394 N·m)
Wheel nut torque value
325 to 398 lbf·ft
(440 to 540 N·m)
Tire tread groove depth 0.062 in (1.6 mm) or more
Tire inflation pressure
COE 40, 45
LT215/85R16-10PR
(Load Range E)
80 psi
(550 kPa)
COE 50
215/75R17.5
124/123L
(Load Range F)
100 psi
(690 kPa)
