11-8 Pretrip inspection and maintenance
2 In the driver’s seat
First, check the shift selector with the engine shut
down. Then start the engine and perform the follow-
ing checks after allowing the engine to warm up.
Coolant level
Check that the coolant level is between the
“FULL” and “LOW” marks on the surge tank.
P. 11 - 3 5
Drive belt
Check the belt for proper deflection when a
force of 22 lb (98 N) is applied to the point mid-
way between the pulleys. Tighten it if neces-
sary.
Check the belt for nicks or other damage.
Replace it if necessary.
P. 11 - 3 9
Engine oil level
Check the engine oil level using either the dip-
stick or the low oil level switch.
P. 11 - 1 8
Coolant, fuel, and oil leaks
Check beneath the vehicle for any sign of
leakage.
Z11188a
Z10749a
Z10750a
Z10751a
Z12716
