11-12 Pretrip inspection and maintenance
3 While walking around the vehicle
Seat belts
Confirm that the seat belt fastens correctly.
P. 4-4
Wheel and tire
Check the disc wheels for cracks and other
damage. Check the tire inflation pressure and
tread groove depth. Check the tires for foreign
objects in the tread grooves, cracks in the
tread, and signs of uneven wear.
P. 11 - 4 5
Crack in tread
Properly inflated
Overinflated
Underinflated
Z11943
Z10752b
Z15025a
