4-3
1.2 Making adjustments
• Slide the seat forward or backward while raising
the seat slide lever . After making the adjust-
ment, release the lever and move the seat back
and forth slightly to lock it in position.
• To adjust the angle of the backrest , raise the
backrest tilt lever .
• Lower the armrest to use it. Turn the armrest
knob to adjust the height of the armrest in its
lowered position.
Up
Down
2 Passenger’s seat
Passenger’s seat
Middle seat
• Pull the backrest tilt lever to adjust the back-
rest angle. While holding the lever, grasp the top
of the backrest and move it forward or backward
to adjust the backrest angle as desired.
• After adjusting the backrest angle or returning
the backrest to its original position after tilting it
forward, gently rock the backrest to make sure it
is locked in place.
• On the passenger’s seat, it is possible to bring
the backrest fully forward. While holding the
lever, grasp the backrest at the top and pull it
forward.
Z10741
Z11806
