Stihl HSE 81

28 HSE 61, HSE 71, HSE 81
: Fit the support plate (1) in the
gear housing (2).
– Install the gearbox plate,
b 5.4.2.
5.6 Replacing the bearing
plate
From serial number 9 72 393 578
5.6.1 Removing the bearing
plate
: Take out the screws (1).
1
1
1
1
: Remove the bottom cover (1).
: Loosen the screws (1) and (2).
: Remove the circlip (3) (only on
models HSE 71, HSE 81).
1
: Remove the bearing plate (1) and
washer(2).
