Stihl HSE 81

31HSE 61, HSE 71, HSE 81
: Remove the cap (1) (see
direction indicated by arrow).
6.1.4 Removing the motor
housing
– Remove the cutting attachment,
b 4.1.1.
– Remove the loop handle,
b 6.1.2.
– Remove the top cover, b 6.1.1.
: Pull off the motor housing (1) in
the direction of the arrow.
1
1
6.1.5 Removing housing half
– Remove the cutting attachment,
b 4.1.1.
– Remove the loop handle,
b 6.1.2.
– Remove the top cover, b 6.1.1.
– Remove the cap, b 6.1.3.
– Remove the motor housing,
b 6.1.4.
: Take out the five screws (1).
1
1
1
1
1
: Pull off the motor housing (1) in
the direction of the arrow.
6.2 Closing the housing
6.2.1 Closing the housing half
: Check that the switch rod (1)
(front) is engaged.
: Check that the two push nuts (2)
are properly fitted in the
openings.
1
2
3
2
1
