Stihl HSE 81

57HSE 61, HSE 71, HSE 81
: Rotate the quadrant (1) in the
direction of the arrow. The
quadrant must snap into position.
: Allow slide (1) to engage in the
quadrant (2).
1
1
2
: Pull the blue wire (1) forward to
take up slack and push it into the
retaining slots.
: Pull the black wire (2) forward to
take up slack and push it into the
retaining slot.
: Fit the front switch lever (1).
– Close the rear handle, b 6.4.4.
– Close the housing, b 6.2.
1
2
1
