– Check the condition of the following fuses:
F1 300 A main fuse
F3 7.5 A main fuse
F1
F3
0252_003-089
Replacing the battery from above for trucks with 1000 kg and
1200 kg capacity
– Before replacing the battery, carry out the
preliminary operations for maintenance:
park the truck on a flat surface, switch off
the truck and then press the emergency off
button.
– Remove the battery hood: open the battery
hood, turn the clasp upwards (3) until it rea-
ches the (B) position and then remove the
hood by sliding it off sideways.
2341
A
B
3
– Disconnect the socket from the battery male
connector.
Maintenance
5
Maintenance plans
108 45728043478 EN - 11/2021 - 09
