Still EXV 10 Basic User Manual

h1 1490 1690 1940 2140 2390 2590
h1' 1565 1765 2015 2215 2465 2665
h2 ------
h2' 150 150 150 150 150 150
h3 2024 2424 2924 3324 3824 4224
h4 2502 2902 3402 3802 4302 4702
h1 initial lift = h1 (standard) + 6 mm
NiHo Triplex
EXV 12/EXV 12 i
h1
1490 1690 1940 2140 2390 2590 1690 1940
h1' --------
h2 1012 1212 1462 1662 1912 2112 1212 1452
h2' --------
h3 2024 2424 2924 3324 3824 4224 3636 4386
h4 2502 2902 3402 3802 4302 4702 4118 4868
h1 initial lift = h1 (standard) + 6 mm
Datasheet (VDI) EXV 14C
and EXV 14iC
EXV 14C
CHARACTERISTICS EXV 14C
Telescopic NiHo Triplex
1.3
Power unit: electric, diesel, petrol,
LPG
Electric
1.4
Drive type: manual, pedestrian,
stand-on, seated, order picker
Pedestrian
1.5 Load capacity Q (kg) 1400
1.6 Load centre
c
(mm)
600
1.8
Load distance, centre of drive axle
to fork
x
(mm)
721 697
1.9 Wheelbase
y
(mm)
1322
Technical data
6
Datasheet (VDI) EXV 14C and EXV 14iC
130 45728043478 EN - 11/2021 - 09
