Stoll CMS 933 - Explanation to the Pictograph (ANSI)

Safety instructions 1
Warning 1.4
1-7
1.4.2 Explanation to the Pictograph (ANSI)
Following Pictographs are used on the machine:
Pictograph Explanation
General Warning indication
Dangerous electrical voltage
Danger of crushing and cutting
Danger from flying-off mechanical parts
or lubricating materials
Danger of suction
Tab. 1-2 Pictographs used on the knitting machine
A warning step comprises of the following parts:
 Safety indications
The safety inidications warns about the danger of injury and death.
In order to avoid death and injuries, all measures that are indicated
alongwith the safety indications are to be followed.
 Signal word
DANGER, WARNING, CAUTION
 Signal color
depending upon the Signal word: red, orange, yellow
Warning step Explanation
Imminent danger of death or serious injuries
(irreversible).
Death of serious injury (irreversible) possible.
Slight injury (reversible) possible.
Damage to property possible
(without Safety indication).
Tab. 1-3 Warning steps for warning instructions as per ANSI
Pictograms on the machine
Warning steps for warning
instructions as per ANSI
