Main components of the knitting machine 3
Front side 3.1
3-1
3 Main components of the
knitting machine
3.1 Front side
Fig. 3-1 Front view of the knitting machine
No. Designation No. Designation
1 Signal light (green,yellow) 9 Engaging rod (red)
2 Yarn control equipment 10 Fabric take-down (main take-
down, auxiliary take-down, take-
down comb)
3 Bobbin board (with yarn bobbin) 11 Fabric collection chamber
4 Carriage 12 Left control cabinet
5 Protective hood (left, right) 13 Needle and additional beds
(front)
6 Cover hoods (over carriage and
needle bed)
14 Touch screen
7 Right control cabinet 15 USB-Connection
8 Main switch (yellow)
