Stoll CMS 933 - Connect the Knitting Machine

Assembly and setting up 4
Assembling machine 4.2
4-5
Preserve the transport locks.
4.2.2 Connect the knitting machine
Valid for:
≥ Component type 003 CMS 822
CMS 933 CMS 830 C CMS 740 CMS 530 T CMS 520
CMS 922 CMS 822 CMS 730 S CMS 530
≥ Component type 002
CMS 730 T CMS 520 C
≥ Component type 000 CMS 420 E
(type 579)
DANGER
High voltage!
Electrical shock may cause death or serious injuries.
Î Deenergize building mains supply.
The knitting machine is connected in the following steps:
 Measuring the mains voltage
 Connecting the mains supply to the main switch
 Adapting the fluff absorption to the mains frequency
The knitting machine must be connected by an electrician. Country-
specific laws and regulations are to be followed.
If the knitting machine is operated by means of a generator, make sure
that the voltage supplied by the generator meets the requirements of the
EN 60204-1, paragraph 4.3.1.
In case of queries, please call the STOLL Helpline.
Mains voltage 400 V
The machine is set for a mains voltage of 400 V as standard. If there is
another mains voltage, then a series transformer is to be used.
Series transformer (ident. number)
CMS 922, CMS 933 253 924
CMS 420, CMS 520, CMS 520 C, CMS 530 253 650
CMS 530 T, CMS 730 S, CMS 730 T,
CMS 740, CMS 822, CMS 830 C
253 923
Tab. 4-1 Series transformer
Authorized personnel
Operating the knitting
machine with a generator
