3 Main components of the knitting machine
3.3 Rear side
3-4
3.3 Rear side
Fig. 3-4 Rear side (without rear panel segments)
No. Designation No. Designation
1 Rear needle bed 5 Trailing cable (energy chain)
2 Carriage 6 Transformer (Fuses)
3 Fluff absorption 7 Control unit on the right
4 Left control unit 8 Main drive
