4 Assembly and setting up
4.2 Assembling machine
4-12
Depending on the mains frequency (50 Hz or 60 Hz), the fluff absorption
operates with or without sealing plugs.
Fig. 4-10 Adapting fluff absorption (on the left: from component type 001 on, on
the right:component type 000)
The fluff absorption can be damaged if the mains frequency is not
adapted!
The fluff absorption is overloaded if it is not adapted to the mains
frequency.
Adapt the fluff absorption to the mains frequency.
1. Open the left cover.
2. Check the sealing plugs (3) of the suction unit.
3. At Mains frequency 50 Hz: Insert sealing plug.
- or -
Î At Mains frequency 60 Hz: Remove sealing plug.
Adapting fluff absorption to
mains frequency
