4 Assembly and setting up
4.3 Mounting yarn feeding and control device
4-16
Fig. 4-16 Position of supports for the yarn control device
5. Release the screw (2) on the left and right-hand sides of the machine,
fold down the track (3) and tighten the screw (2) again.
6. Tighten the screw for fastening the rear track in the center of the
machine.
7. Hook in both additional bobbin boards (4).
The additional bobbin boards (4) are not supplied as standard with some
machine types. They are available as a special equipment.
