Modules & Options
6 - 22 3G/4G Module
6
3G/4G Module USIM Card Installation
Follow the instructions below to install the USIM card (which will be provided by
your service provider).
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow.
3. Slide the latch in the direction of the arrow, and hold it in place.
4. Slide the battery out in the direction of the arrow .
5. Insert the USIM card (at the rear of the battery compartment) as illustrated
below until it clicks fully into position, and replace the battery.
Power Safety
Warning
Before you undertake any
installation procedures,
make sure that you have
turned off the power, and
disconnected all peripher-
als and cables.
USIM Card Orientation
Note that the USIM card’s
readable side (with the
gold-colored contacts)
should face upwards as il-
lustrated.
Figure 6 - 17
USIM Card Insertion
To Next Page
