Stone Stonebook Mini - System Map: Bottom View

1 - 14 System Map: Bottom View
Quick Start Guide
1
System Map: Bottom View
Figure 1 - 7
Bottom View
1. Battery Location
2. Vent/Fan Intake/
Outlet
3. Speakers

Overheating
To prevent your comput-
er from overheating
make sure nothing blocks
the Vent/Fan Intake while
the computer is in use.
1
3

Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may
violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please
contact your distributor/supplier for further information.
3
2
