Reference
Appendix M1
M1-3
®
10MAY01
Unnotched Impact (ft*lb/in): 0.92
Elongation (%): 10.00+
Hardness (Shore D): 33.00
Softening Point (R&B) (F): 177
Specific Gravity (GMS/CM
3
):1.00
Tensile Strength (psi): 509
Flexural Strength (psi): 619
Tensile Modulus (psi): 40,000
Flexural Modulus (psi): 40,000
Notched Impact (ft*lb/in): 0.32
Material Specifications*
It is recommended to use the parameter values indicated in bold for
perimeter roads. The values in this table may also be applied to fill
and support roads if desired.
Speed inches/sec
(maximum)
(recommended)
Road Height
(maximum)
(minimum)
(recommended)
Road Width
(maximum)
(minimum)
Liquefier Temp °C
(maximum)
(minimum)
(recommended)
Envelope Temp °C
(maximum)
(minimum)
(recommended)
Room Temp °F
(maximum)
0.025"
0.016"
0.800
0.800
0.014"
0.010"
0.010"
0.040"
0.016"
74
72
73
45
38
43
72
0.800
0.800
0.014"
0.010"
0.012"
0.090"
0.025"
74
72
73
45
38
43
72
FDM System
Parameters
FDM Tip Inner Diameter
ICW06 - Investment Casting Wax
FDM 1600, 1650, 2000, and 3000
* Material specifications are based on ASTM tests.
Note: The .025 tip is
only available for the
FDM 1600 and FDM
1650.
