ReferenceM1-4
Materials Appendix
10MAY01
Materials Plastic
Speed inches/sec
(maximum)
(recommended)
Road Height
(maximum)
(minimum)
(recommended)
Road Width
(maximum)
(minimum)
Liquefier Temp °C
(maximum)
(minimum)
(recommended)
Envelope Temp °C
(maximum)
(minimum)
(recommended)
Room Temp °F
(maximum)
FDM Tip Inner Diameter
FDM System
Parameters
P301 - Plastic Material (Polyamide)
FDM 1500 and 1600
0.025"
0.016"
0.500
0.500
0.014"
0.010"
0.010"
0.050"
0.016"
155
130
See Spool
40
10
40
82
0.700
0.500
0.020"
0.010"
0.010"
0.090"
0.030"
155
130
See Spool
40
10
40
82
It is recommended to use the parameter values indicated in
bold for perimeter roads. The values in this table may also be
applied to fill and support roads if desired.
The properties of P301 require a minimum of 1-2 minutes
between deposited layers to solidify. The maximum wait
time allowed by the hardware controller is 60 seconds. For
small geometry, multiple parts can be modeled to achieve a 2
minute wait between z levels.
Unnotched Impact (ft*lb/in): 1.46
Elongation (%): 3.48
Hardness (Shore D): 70D
Softening Point (R&B) (F): ----
Specific Gravity (GMS/CM
3
):1.10
Tensile Strength (psi): 1,765
Flexural Strength (psi): 2,113
Tensile Modulus (psi): 80,000
Flexural Modulus (psi): 60,000
Notched Impact (ft*lb/in): 0.24
* Material specifications are based on ASTM tests.
Material
Specifications*
